เครื่องหาปลา โซน่าหาปลาแบบบลูทูธเชื่อมต่อโทรศัพท์ Sonar Wireless Fish Finder Sonar Sensor Fishing Sounder Bluetooth Fish Detect Device iOS/Android ยี่ห้อ Outlife

รหัส SNF017
ราคา 2,850 บาท

SNF017

สินค้าหมดแล้ว

แจ้งความต้องการสินค้า

รายละเอียดสินค้า

เครื่องหาปลา โซน่าหาปลาแบบบลูทูธเชื่อมต่อโทรศัพท์ Sonar Wireless Fish Finder Sonar Sensor Fishing Sounder Bluetooth Fish Detect Device iOS/Android ยี่ห้อ Outlife

>> เช็คสต๊อคสินค้า <<



เครื่องมือหาปลารุ่นนี้ ใช้เทคโนโลยีคลื่นโซน่าเพื่อค้นหาตำแหน่งของปลา หรือ ฝูงปลา แม้ว่าจะอยู่ในจุดที่มีสิ่งกีดขวางที่อยู่ใต้น้ำ เมื่อคลื่นโซน่าถูกส่งไปกระทบกับของแข็ง มันจะสะท้อนกลับมายังเซนเซอร์ตรวจจับ แล้วแสดงผลค่าความลึกของระดับน้ำ เครื่องมือนี้สามารถใช้ได้ทั้งในท้องทะเล แม่น้ำ ทะเลสาป หรือแม้แต่ทะเลสาปน้ำแข็ง การใช้งานง่าย สามารถติดยึดได้สี่รูปแบบ

  1. ยึดไว้กับตัวเรือ
  2. ยึดกับทุ่นลอยน้ำ
  3. ยืคไว้กับแท่งไม้ หรือ แท่งเหล็ก เพื่อจุ่มลงไปในน้ำ
  4. วางไว้บนพื้นผิวน้ำแข็ง

โซน่าเทคโนโลยี ใช้หลักการเกี่ยวกับคลื่นเสียง เครื่องมือนี้จะอาศัยคลื่นเสียงนี้ กระทบกับวัตถุต่างๆ แล้วสะท้อนกลับมายังเซนเซอร์ เพื่อแยกแยะวัตถุนั้นๆ ระดับความลึกของพื้น และลักษณะของพื้นผิว เมื่อโซน่าส่งคลื่นเสียงออกไป จะสามารถคำนวณระยะทางได้โดยการจับเวลาการเดินทางของคลื่นเสียงระหว่างตัวส่งโซน่าไปกระทบวัตถุนั้นๆ แล้วสะท้อนกลับมา ตัวเครื่องจะทำการแปลงสัญญาณที่ได้รับแล้วแสดงให้รู้ว่าวัตถุเหล่านั้นมีลักษณะเป็นอย่างไร ขนาดเล็กใหญ่ เป็นต้น

รีวิวสินค้า


Features:

  • Sonar fishing identifying technology: works in conjunction with smart phones and tablets, detection data is transmitted to the phone in real time, allows you to map water beds, mark spots, log water temps and depth, add lures, species and video in the trip log.
  • Free App on iOS or Android: “Fish Helper” syncs via Bluetooth smart to the device. Bluetooth connection secures the distance between the device and its user up to 118 feet / 36 meters.
  • Fish alarm, noise filter, 90-degree sensitivity for the user to select, sonar frequency is 125KHz, depth up to 118ft / 36m, with rechargeable 3.7V lithium-ion battery, the using time is up to 6 – 8 hours.
  • Lightweight and useful: weighing just 0.074kg and measuring 1.97 inches in diameter, the diminutive device is suitable for every standard rods and lines.
  • Wide application: ideal for kayak, canoe fishing, ice fishing, works both in saltwater and freshwater, effective at locating fish and structures on ponds, lakes, streams and rivers.

Parameters:
Wireless Sonar Sensor:

  • Depth Range: 2 – 118ft / 0.6 – 36m
  • Sonar Frequency: 125KHz
  • Sonar Radiation Angle: 90 degree
  • Bluetooth Distance: 30m
  • Operational Temperature: -10 – 60 Deg.C

Power Supply:

  • Mainframe: 3.7V rechargeable lithium-ion battery (included)
  • Charging Time: 3 hours
  • Endurance Time: 6 – 8 hours
  • Lifespan: 2 – 3 years

How to Use:

  1. Download the App “Fish Helper” file to your mobile phone (Android), then click to install, then a “Fish Helper” App icon on your mobile phone
  2. Open the BT inside the “setting” of your phone. Click “Fish Helper” App and enter the main interface
  3. Throw the sensor the water, the water switch will power on the sensor. Click “setting”, pop up setting interface. After pairing, the product starts to work (the white LED is blinking)
  4. After the phone and the sensor connection, the device will automatically enter the last time mode. If you need to detect, please confirm whether it is working mode. Otherwise, the device will not detect properly
  • Package weight: 0.234 kg
  • Package Size(L x W x H): 10.00 x 10.00 x 7.50 cm / 3.94 x 3.94 x 2.95 inches

Package Contents:

  • 1 x Wireless Sonar Sensor (Battery Included)
  • 1 x English User Manual
  • 1 x Charging Cable
  • 1 x CD Disk
