This scanner features the most advanced 32 bit duplex ARM + DSP digital signal processing technology. Holds 256 KB worth of memory and 2600 data string readings without a connection. It also comes with a 1500mAh li-Ion battery with more than half a year of standby time.

Specifications:

• Symbologies: 1D codes
• Depth of field: 10-800mm
• Resolution: 0.01mm (4 mil) Communication
• Distance: 300-500m
• Decode Speed120 times/ sec.
• Bite Error Rate: 1/5 million
• Battery: Li-battery, last 6 hours after full charged.

Features:

• Elegant appearance,humanized design
• Long communication distance;150m indoors and 300m outdoors
• USB data receiver,play and plug,easy to operate
• Supporting network construction;1 base to 254 readers or 15 bases to 1 reader;ID display
• Repeated code detection;no messy-code programmed
• Free of charging trouble;battery lasts 6-10 hours after full charged;base functions as receiver and charger

Parameters:

• Light Source: 650nm laser (safe visible light)
• Operating Channel: 433MHz|SM
• Communication Distance: 150m indoor;300m outdoor
• Supported Symbologies: Code 39,full ASCII, code bar, industrial 2 of 5, interleave 2 of 5, matrix 2 of 5, code 93, code 128, code 32, standard code 93, EAN 128, MSI, EAN8&13,UPCA&E, Plessey, DataBar14, telepe and all 1D barcode
• Precision: ≥0.1mm
• Depth of Scan Field : 10-800mm
• Interface: USB,RS232,PS/2
• Operation: Manual/Automatic
• Decode Speed: 120times/second
• Light Intensity: Daylight,4000Lux
• Decode Error Rate: less than 1/8 million
• Print Contrast Signal: ≥30°
• Scan Angel: Yaw(Skew) 45° Pitch 60°
• Safety: Full quakeproof, dustproof, antiknock-design and EMI Shielding

Mechanical/Electrical

• Voltage: 5V
• Current: Operation 68mA;Idle 48mA
• Scanner Material: Eco-friendly

Environment

• Operation Temperature: -20°-45°
• Storage Temperature: -20°-45°
• Humidity: 5%-85%

Size chart
